Price range: $595.92 through $940.71
Welcome to Ortur Official Store, please note:
a. New Arrival! Best sales of the year!
b. Lots of stock available in China warehouse now , prompt delivery can be made once order confirmed.
c. Freeshipping is not means free duty. As we all known, import high value goods would be charged import tax in each country;
Package Details
ALDK: Laser engraving machine
ALDK-Kit 1:: Laser engraving machine+ plywood
ALDK-Kit 2: Laser engraving machine+ cutting table
ALDK-Kit 3: Laser engraving machine + rotary device+ raiser feet
ALDK-Kit 4: laser engraving machine + cutting table + plywood
ALDK-Kit 5: Laser engraving machine + cutting table + rotating device+ raiser feet
ALDK-Kit 6: Laser engraving machine + cutting table + plywood + Lightburn license (software)
ALDK-Kit 7:: Laser engraving machine + plywood + raiser feet + rotating device
ALDK-Kit 8: Laser Engraver + cutting Table + rotary device +raiser feet+ Lightburn License (Software)
ALDK-Kit 9:: Laser engraving machine + cutting table + raiser feet +plywood
Note: Lightburn is a software that requires a license to be activated. If you do not purchase a license, it will not affect the normal use of the laser engraving machine. We will provide free Laser GRBL
Product Details:
Latest Laser Beam Shaping Technology: Algolaser DIY Kit uses the latest 5.5W laser beam shaping technology diode laser, it has an ultra-fine 0.08mm sharp laser focus, with super cutting penetration and precision, can cut up to 8mm thick wood, 5mm acrylic, carve ceramics and stainless steel.
Offline Control: Support mobile APP control, wifi connection, USB connection, offline USE，The machine is compatible with various mature engraving software, such as LaserGRBL, LightBurn, Benbox, GrblController, LiteFire, supports PWM mode engraving, supports Windows Mac system, and engraving file format Support JPG, PNG, DXF, SVG, G-code, NC, BMP, etc.
Upgraded 32-bit Motherboard/Dual-core CPU: Deliver significant speed boost, achieving an impressive 32% higher CPU performance and 50% improved energy efficiency.8MB RAM, 8MB storage memory, and a built-in 32GB SD card
Easy to Upgrade and Expand: The upgraded terminals of the motherboard, as well as modularization design of DIY kit, allows users to extend the existing frame and connect other accessories to achieve more possibilities.
User-friendly Installation: There are few cables need to connect and each one it’s just the right length for its position. The assembly takes only 10~25 mintutes with instruction help, even for newbies.
Square Measuring Ruler: X-axis and Y-axis contain precise scale lines, which is convenient for you to measure the size of engraving objects quickly.
Safe Design: 7 Safety Protections
Machine Offset Detection and Protection
Machine Tilt Detection and Protection
USB Connection Detection and Protection
Beam detection and protection
Current and Voltage Detection and Protection
Emergency Stop Switch
Key Lock
Machine Parameters:
Model: Algolaser DIY Kit
Machine Weight: 5kg
Engraving Range: 400 * 400mm
Laser Wavelength: 445 ± 5nm
Engraving Accuracy: 0.1mm
Engraving Speed: 12000mm / min
Software Support System: MAC, Windows
Machine Material: Aluminum Profile
Power Supply: INPUT:100-240~50/60Hz OUTPUT:24V3A（6A MAX）
Control Board: ALGOLASER_DIY_KIT_V1.232 Motherboard (32bit)
Laser Power: 5-5.5w
Input Power: 72W
Software Identification File Format: NC, BMP, JPG, PNG, Gcode, Etc
Supporting software: Lasergrbl (Windows system), Lightburn (General)
Power type: US/AU/UK/EU
Languages Supported By The Software: Chinese, English, Italian, French and German
Working Environment: Temperature 5-40 ℃, Humidity 20-60%
Engraving Mode: USB Online, TF Card Offline (Application Program, Web Page Control)
Carving Materials: Wood, Plastic, Paper, Leather, MDF, Sponge Paper, Alumina, Etc
Engraving Mode: Graphic Engraving, File Engraving, Scanning Engraving, Contour Engraving And Pixel Engraving
Note: Transparent materials cannot be cut or engraved directly, and the surface needs to be covered.
Welcome to AlgoLaser Manufacturing Store, we dedicated to offering you laser engraving machines with Fast Delivery, Easy Options, Reliable Quality and Affordable Price. We have lots of inventory in Russian, Czech republic, Spain, United States, United Kingdom, Japan, Mexico, Brazil and China warehouse, about 3-7 Business Days Fast & Free Shipping. And we are original AlgoLaser manufacturer in China, you could rely on us for the consistent quality and service!
