Features:
Solid And Easy Installation Structure Design:All-aluminum alloy anodized structure design makes the machine more durable, and improves the accuracy of engraving. The entire machine structure can generally be completed within 10-20 minutes.
New Filter Eye conservation Acrylic Design:The filter acrylic protective cover plays a good role in protecting your eyes, filtering 97% of ultraviolet light, free to watch the laser engraving without goggles.
Upgraded High-Performance Fixed-Focus Laser:No need to adjust the focus before engraving and more stable than the zoom laser as well; The new laser focal spot is 50% smaller than other ordinary lasers, new laser combine precision engraving and high energy cutting at the same time. The laser power of the fixed-focus laser is more stable than the zoom laser.
Newly Upgraded Ultra-Fine Compression Laser: Adopts 4-fold lens group collimation and focus technology, the optical power is 5-5.5W, laser focus area is reduced to 0.08*0.08mm. The high-density laser can easily cut 15mm thick wooden boards, 15mm black acrylic; Directly engrave mirror stainless steel metal and ceramics, and can achieve the effect of a 100W CO₂ laser engraving machine.
Precise Scale Lines Axis :There are precise scale lines on the X-axis and Y-axis to facilitate quick length measurement. 410x400mm large area engraving interval can meet your various engraving needs.
Wide Compatibility:The machine can be compatible with various mature engraving software, such as LaserGRBL, LightBurn, support Win XP / Win 7 / Win 8 / XP / Win 10, and also support MAc system (LightBurn), engraving file format supports NC, BMP, JPG, PNG, DXF etc.
More Function:Uses an integrated screw rod which makes the movement of the laser more precise and the coupling more durable. In the event of an unexpected situation, stop the machine at any time to make the engraving safer. The laser sintering temperature is up to 800~850℃.
Specification:
Item Model: Atomstack A5 M50
Engraving Area: 410*400mm
Carving Materials: Wood, Bamboo, Cardboard, Plastic, Leather, Mdf, Slate, Lacquered Metal, Mirror Stainless Steel
Cutting Material: Cardboard, Non-Woven Fabric, Veneer, Acrylic, Some Thin Plastic Board, Sponge, Mdf, Leather
Laser Power: 40W
Laser Output Power: 5-5.5W
Wave Length: 445 ± 5nm
Engraving Accuracy: 0.01mm
Focusing Method: Fixed Focus Laser, No Need To Focus
Laser Protective Cover: Protect The User’s Eyes And Prevent Pets From Grabbing The Laser Spot.
Operating Software: LASERGRBL, LIGHTBURN, Support Win XP / Win 7 / Win 8 / XP / Win 10 System.
Input Format: NC, BMP, JPG, PNG, DXF, ETC.
Data Transmission Method: USB Connection.
Input Voltage: AC 100-240V, 50/60hz
Output Voltage: DC12V, 5A
Certification: CE FCC ROHS FDA
Equipment Net Weight: 4.3kg
Equipment Size: 570*600*270mm
Packing Size: 620*345*130mm/24.4*13.6*5.1in
Package Weight: 5.072kg/11.1lbs
Packing List:
1 x X-Axis Assembly
2 x Section 57cm
2 x Section 48cm
1 x Control Box
3 x Support Legs
1 x Goggles
1 x Laser
1 x 24V 2A Power Adapter
1 x Power Switch Line
1 x USB Cable
Step 1~5 Installation Package
1 x M5 Wrench
10 x Rolled Belt
3 x Small Wood
1 x Focal Length Film
1 x M3 Wrench
1 x Brush
3 x Small Acrylic
1 x Stainless Steel Backing Plate For Cutting
Atomstack Maker APP is suitable for all models.
APP v1.1.7 is now available. Download address: https://atomstack.com/pages/atomstack-studio-software
